Hammer Mills: Working Principle, Types, and Applications
A hammer mill is one of the oldest and most commonly used size reduction machines, composed of multiple hammers (typically four or more) hinged onto a central shaft and enclosed within a robust metal casing.Â
These machines are specifically designed to crush and break solid and hard materials, widely utilized in various industries such as mining, minerals, chemicals, food processing, cosmetics, and construction. Hammer mills efficiently deliver uniform particle size reduction while ensuring reliable operation.
Advantages of Hammer Mills
Cost-effective with low energy consumption, reducing operational costs.
Capable of grinding and crushing various materials at high speeds.
High reduction ratio and capacity suitable for primary, secondary, or tertiary grinding.
Effective dynamic size reduction, especially beneficial for brittle materials.
Easy and straightforward installation with continuous operational capabilities.
Produces specified particle sizes without needing a closed-circuit system. Compact, easy to clean, and maintain.
Working Principle and Key Components:
Hammer mills perform size reduction using hardened steel rectangular hammers rotating rapidly inside a milling chamber. These swinging hammers, mounted on a central shaft, strike materials forcefully, breaking them into smaller pieces.
Key Components:
Feeding Mechanism:
Introduces materials into the crushing chamber.
Types include gravity-fed (using gravitational force) or metered feeding (for precise material consistency).
Control Box (Control Panel):
Interface between operator and machine.
Controls milling speed and monitors operational performance through a display.
Crushing Hammers/Knives:
Primary crushing/grinding elements rotating at speeds of 2000 to 6000 rpm.
Rotation can be clockwise or anticlockwise, controlled via the control panel.
Pulverizer Screens:
Filters fine material from coarse after crushing.
Selection depends on the desired output particle size.
Types of Hammer Mills:
Lump Breakers: Designed to convert lumps into powder or paste, ideal for brittle materials like bonded chemical salts, lime chunks, and clinker ash.
Pneumatic Discharge Hammer Mills (PDHM): Features thin chamber walls and hammers, incorporating air evacuation systems enhancing output. Suitable for lighter materials such as paper and biomass.
Gravity Discharge Industrial Hammer Mills: Employ swinging hammers mounted on a shaft for particle size reduction through direct hammering and particle-on-particle collisions. Commonly used for crushing glass, ceramics, and dry chemicals.
Full Circle Screen Hammer Mills: Equipped with a 300-degree rotating screen improving particle evacuation efficiency, suitable for lightweight materials like spices and grasses.
Horizontal In-Feed Hammer Mills: Materials fed horizontally, primarily designed for heavy-duty grinding of tough materials. Commonly used in industrial settings, featuring grinders for pallets and trim scraps.
Applications of Hammer Mills:
Food Product Grinding: Grinding legumes, beans, soya, and nutshells in food processing industries.
Powder Production: Generating intermediate-grade powders for chemical and pharmaceutical industries.
Material Size Reduction: Micronizing pharmaceutical grains for precise capsule packaging.
Mixing Solid Dry & Fibrous Materials: Producing uniform mixtures of dry and fibrous solids.
Dissolution Processes: Accelerating dissolution rates in chemical, food, and pharmaceutical formulations.
Enhancing Ingredient Activity: Slight crushing to activate reactive properties in formulations.
Scrapping and Recycling: Crushing irreparable automobile parts and recycling the resulting metal.
Jay Khodiyar Hammer Mills Machine Manufacturer
Jay Khodiyar is a leading manufacturer of biomass hammer mill machines in India. Their high-quality mills efficiently process agricultural and forest waste into fine particles, ideal for briquette and pellet production. With capacities ranging from 3,000 to 8,000 kg/hr, these machines are essential for sustainable energy solutions.
